Exploring Operating Systems
Day 23: Memory Allocation Internals (malloc, free)
Table of Contents
- Introduction
- Memory Allocator Design
- Memory Block Structure
- Allocation Strategies
- Free List Management
- Custom Memory Allocator Implementation
- Memory Coalescing and Splitting
- Performance Optimization
- Debugging and Profiling
- Conclusion
- References
1. Introduction
Memory allocation is a fundamental operation in computer systems. It involves complex algorithms to manage memory efficiently and dynamically. This topic explores the internals of memory allocation, focusing on the implementation of a custom memory allocator that mimics the behavior of malloc and free. Understanding these internals is crucial for developing robust and performant software.
This topic delves into the core concepts and techniques behind dynamic memory management. It goes beyond the surface level of malloc and free, exploring data structures, algorithms, and optimization strategies for building a custom memory allocator.
2. Memory Block Structure
The memory block structure is a crucial data structure in dynamic memory allocation. It contains information about each allocated or free memory block, including its size, allocation status, and pointers for linking blocks together. This structure allows the allocator to keep track of the available memory space.
The structure definition includes fields for the block size, a flag indicating if the block is free or allocated, and pointers for linking blocks in a free list or used list. The structure also includes a flexible array member to store the actual data for the allocated block.
#include <stdio.h>
#include <stdlib.h>
#include <string.h>
#include <stdbool.h>
#include <assert.h>
#include <unistd.h>
#define ALIGNMENT 8
#define ALIGN(size) (((size) + (ALIGNMENT-1)) & ~(ALIGNMENT-1))
#define BLOCK_SIZE sizeof(block_t)
typedef struct block_t {
size_t size; // Size of the block including header
bool is_free; // Whether block is free
struct block_t* next; // Next block in the list
struct block_t* prev; // Previous block in the list
char data[1]; // Start of the data (flexible array member)
} block_t;
typedef struct {
block_t* free_list; // Head of free blocks list
block_t* used_list; // Head of used blocks list
size_t total_size; // Total heap size
size_t used_size; // Total used size
} heap_t;
3. Custom Memory Allocator Implementation
Below you can see the implementation of a custom memory allocator. It includes functions for initializing the heap, finding suitable free blocks, splitting blocks, allocating memory (custom_malloc), freeing memory (custom_free), and coalescing adjacent free blocks. This implementation provides a concrete example of how a memory allocator operates.
The custom_malloc implementation uses a best-fit allocation strategy. It searches the free list for the smallest free block that can satisfy the request. The custom_free function frees the allocated memory and merges adjacent free blocks to reduce fragmentation.
// Global heap structure
static heap_t heap = {0};
void init_heap(size_t initial_size) {
initial_size = ALIGN(initial_size);
// Request memory from OS
void* memory = sbrk(initial_size);
if (memory == (void*)-1) {
perror("Failed to initialize heap");
return;
}
// Initialize first block
block_t* initial_block = (block_t*)memory;
initial_block->size = initial_size;
initial_block->is_free = true;
initial_block->next = NULL;
initial_block->prev = NULL;
// Initialize heap structure
heap.free_list = initial_block;
heap.used_list = NULL;
heap.total_size = initial_size;
heap.used_size = 0;
}
// Find best fit block
block_t* find_best_fit(size_t size) {
block_t* current = heap.free_list;
block_t* best_fit = NULL;
size_t smallest_diff = SIZE_MAX;
while (current != NULL) {
if (current->is_free && current->size >= size) {
size_t diff = current->size - size;
if (diff < smallest_diff) {
smallest_diff = diff;
best_fit = current;
// If perfect fit, stop searching
if (diff == 0) break;
}
}
current = current->next;
}
return best_fit;
}
void split_block(block_t* block, size_t size) {
size_t remaining_size = block->size - size;
// Only split if remaining size is large enough for a new block
if (remaining_size > BLOCK_SIZE + ALIGNMENT) {
block_t* new_block = (block_t*)((char*)block + size);
new_block->size = remaining_size;
new_block->is_free = true;
new_block->next = block->next;
new_block->prev = block;
if (block->next) {
block->next->prev = new_block;
}
block->next = new_block;
block->size = size;
}
}
void* custom_malloc(size_t size) {
if (size == 0) return NULL;
// Adjust size to include header and alignment
size_t total_size = ALIGN(size + BLOCK_SIZE);
// Find suitable block
block_t* block = find_best_fit(total_size);
// If no suitable block found, request more memory
if (block == NULL) {
size_t request_size = total_size > 4096 ? total_size : 4096;
void* memory = sbrk(request_size);
if (memory == (void*)-1) {
return NULL;
}
block = (block_t*)memory;
block->size = request_size;
block->is_free = true;
block->next = heap.free_list;
block->prev = NULL;
if (heap.free_list) {
heap.free_list->prev = block;
}
heap.free_list = block;
heap.total_size += request_size;
}
// Split block if necessary
split_block(block, total_size);
// Mark block as used
block->is_free = false;
// Remove from free list and add to used list
if (block->prev) {
block->prev->next = block->next;
} else {
heap.free_list = block->next;
}
if (block->next) {
block->next->prev = block->prev;
}
block->next = heap.used_list;
block->prev = NULL;
if (heap.used_list) {
heap.used_list->prev = block;
}
heap.used_list = block;
heap.used_size += block->size;
return block->data;
}
// Coalesce adjacent free blocks
void coalesce_blocks(block_t* block) {
// Coalesce with next block
if (block->next && block->next->is_free) {
block->size += block->next->size;
block->next = block->next->next;
if (block->next) {
block->next->prev = block;
}
}
// Coalesce with previous block
if (block->prev && block->prev->is_free) {
block->prev->size += block->size;
block->prev->next = block->next;
if (block->next) {
block->next->prev = block->prev;
}
block = block->prev;
}
}
void custom_free(void* ptr) {
if (!ptr) return;
// Get block header
block_t* block = (block_t*)((char*)ptr - BLOCK_SIZE);
// Mark block as free
block->is_free = true;
// Remove from used list
if (block->prev) {
block->prev->next = block->next;
} else {
heap.used_list = block->next;
}
if (block->next) {
block->next->prev = block->prev;
}
block->next = heap.free_list;
block->prev = NULL;
if (heap.free_list) {
heap.free_list->prev = block;
}
heap.free_list = block;
heap.used_size -= block->size;
// Coalesce adjacent free blocks
coalesce_blocks(block);
}
void print_memory_stats() {
printf("\nMemory Statistics:\n");
printf("Total Heap Size: %zu bytes\n", heap.total_size);
printf("Used Size: %zu bytes\n", heap.used_size);
printf("Free Size: %zu bytes\n", heap.total_size - heap.used_size);
printf("\nFree Blocks:\n");
block_t* current = heap.free_list;
while (current) {
printf("Block at %p, size: %zu\n", (void*)current, current->size);
current = current->next;
}
printf("\nUsed Blocks:\n");
current = heap.used_list;
while (current) {
printf("Block at %p, size: %zu\n", (void*)current, current->size);
current = current->next;
}
}
4. Memory Profiling and Debugging Tools
Debugging and profiling memory allocation is essential for identifying leaks, fragmentation, and performance bottlenecks. The provided code includes functions for detecting memory leaks, printing memory statistics, and performing simple debugging tasks.
The debug_malloc and debug_free functions track allocated memory and allow for the detection of memory leaks. The print_memory_stats function provides information about total, used, and free memory, helping to understand memory usage patterns.
typedef struct {
void* ptr;
size_t size;
const char* file;
int line;
} allocation_info_t;
#define MAX_ALLOCATIONS 1000
static allocation_info_t allocations[MAX_ALLOCATIONS];
static int allocation_count = 0;
void* debug_malloc(size_t size, const char* file, int line) {
void* ptr = custom_malloc(size);
if (ptr && allocation_count < MAX_ALLOCATIONS) {
allocations[allocation_count].ptr = ptr;
allocations[allocation_count].size = size;
allocations[allocation_count].file = file;
allocations[allocation_count].line = line;
allocation_count++;
}
return ptr;
}
void debug_free(void* ptr, const char* file, int line) {
for (int i = 0; i < allocation_count; i++) {
if (allocations[i].ptr == ptr) {
memmove(&allocations[i], &allocations[i + 1],
(allocation_count - i - 1) * sizeof(allocation_info_t));
allocation_count--;
break;
}
}
custom_free(ptr);
}
void check_leaks() {
if (allocation_count > 0) {
printf("\nMemory Leaks Detected:\n");
for (int i = 0; i < allocation_count; i++) {
printf("Leak: %zu bytes at %p, allocated in %s:%d\n",
allocations[i].size, allocations[i].ptr,
allocations[i].file, allocations[i].line);
}
} else {
printf("No memory leaks detected\n");
}
}
5. Usage Example of Custom Allocator
Below you can see how to use the custom memory allocator through a simple example in the main function. It includes memory allocation and deallocation, printing memory statistics, and checking for memory leaks.
int main() {
init_heap(1024 * 1024);
int* numbers = (int*)custom_malloc(10 * sizeof(int));
char* string = (char*)custom_malloc(100);
for (int i = 0; i < 10; i++) {
numbers[i] = i;
}
strcpy(string, "Hello, World!");
print_memory_stats();
custom_free(numbers);
custom_free(string);
check_leaks();
return 0;
}
6. Performance Optimization Techniques
Techniques for optimizing memory allocation performance include memory alignment, cache-friendly block placement, and memory preallocation strategies. These techniques aim to improve memory access patterns, reduce fragmentation, and increase overall allocator efficiency.
Memory Alignment The code includes examples of memory alignment to ensure efficient memory access and cache-friendly block placement to optimize data locality, which can lead to significant performance improvements in real-world applications.
// Optimize memory alignment for different architectures
#if defined(__x86_64__) || defined(_M_X64)
#define ALIGNMENT 16
#else
#define ALIGNMENT 8
#endif
Cache-friendly Block Placement
// Place frequently accessed metadata at the start of the block
typedef struct block_t {
size_t size; // Most frequently accessed
bool is_free; // Second most frequently accessed
struct block_t* next; // Less frequently accessed
struct block_t* prev; // Less frequently accessed
char data[]; // Actual data
} __attribute__((aligned(ALIGNMENT))) block_t;
7. Conclusion
A custom memory allocator provides fine-grained control over memory management, enabling improved performance, debugging capabilities, and a deeper understanding of system-level memory allocation. However, it also introduces complexities related to fragmentation, thread safety, and cache management.
8. References and Further Reading
- “The C Programming Language” by Kernighan and Ritchie
- “Advanced Programming in the UNIX Environment” by W. Richard Stevens
- “Understanding and Using C Pointers” by Richard Reese
- Doug Lea’s Memory Allocator Documentation
- “Memory Systems: Cache, DRAM, Disk” by Jacob, Ng, and Wang
